LAN Cable

Fixed-installation structured cable from Cat5e through Cat7 in solid bare copper.

ANSI/TIA-568-C.2
ISO/IEC 11801
IEEE 802.3af/at

Request a quote

Technical specification

Part numbers: JBLC12 (Cat5e), JBLC10 (Cat6)
Categories: Cat5e, Cat6 and Cat7
Conductor: Bare solid copper - 24 AWG (Cat5e), 23 AWG (Cat6)
Impedance: 100 +/- 15 Ohm - 1-100 MHz (Cat5e), 1-250 MHz (Cat6)
DC resistance at 20 C: 9.5 Ohm/100 m (Cat5e), 8.4 Ohm/100 m (Cat6)
DC resistance unbalance: Max 2.5%
Capacitance unbalance: 330 pF/100 m pair-to-ground
Insulation resistance: > 5000 MOhm x km
Dielectric strength: 2500 V DC, 2 s
Rated temperature: 75 C
Shielding: UTP, FTP and S/FTP options
Jacket: PVC or LSZH by selection, descending length markings

Typical useStructured premises cabling and digital data networks, including Power over Ethernet.

Catalog page (JPG) ↗

1 product in this category

All variants share the specification above. Core count, colour and construction vary.

LAN Cable

Quote this cable
