FIRE & SAFETY

Security Alarm & Control Cable

Multi-core alarm and control cable from 2 to 20 cores, shielded and unshielded.

RoHS

Request a quote

Technical specification

Structure: 24 AWG / 22 AWG, shielded or unshielded
Conductor material: CCA, TC, BC or TCCA - solid or stranded
Conductor size: 7 x 0.18 / 0.19 / 0.20 mm
Cores: 2, 4, 6, 8, 10, 12, 14, 16, 18 and 20
Insulation / jacket: PVC
Shield: Aluminium foil with 7 x 0.2 mm drain wire
Rip cord: Nylon fibre
Operating voltage: 300 V RMS max
DC resistance: 206.43 Ohm/kft per conductor
Capacitance: 35 pF/ft at 1 kHz between conductors
Temperature range: -20 C to +60 C

Typical useSecurity systems, alarm signalling, detector and sensor connections, and low-voltage control circuits.

Catalog page (JPG) ↗

9 products in this category

All variants share the specification above. Core count, colour and construction vary.

White 2 Core Stranded Unshielded Security Alarm Cable

White 2 Core Stranded Unshielded Security Alarm Cable Specification

White 2 Core Stranded Shielded Security Alarm Cable

White 2 Core Stranded Shielded Security Alarm Cable Specification

White 4 Core Stranded Unshielded Security Alarm Cable

White 4 Core Stranded Unshielded Security Alarm Cable Specification

White 4 Core Stranded Shielded Security Alarm Cable

White 4 Core Stranded Shielded Security Alarm Cable Specification

White 6 Core Stranded Unshielded Security Alarm Cable

White 6 Core Stranded Unshielded Security Alarm Cable Specification

White 6 Core Stranded Shielded Security Alarm Cable

White 6 Core Stranded Shielded Security Alarm Cable Specification

8 Core Stranded Shielded Security Alarm Cable

8 Core Stranded Shielded Security Alarm Cable Specification

White 2+6 Core Stranded Shielded Security Alarm Cable

White 2+6 Core Stranded Shielded Security Alarm Cable Specification

White 2+8 Core Stranded Shielded Security Alarm Cable

White 2+8 Core Stranded Shielded Security Alarm Cable Specification
